Dell'Orto carburetor PHBG 17.50 mm AD

Standard Dell'orto factory configuration.

Type: PHBG 17.50 AD = 2-stroke carburetor

Adjustment screws: Right

Mixer/venturi: 17.5 mm

Main jet: 82

Idle jet: 55

Starter/choke jet: 55

Emulsion tube type: AN262

Needle type: W6

Throttle slide type: 30° = ref. 9475.30

Choke connection type: cable or pull lever (cables or pull lever not included)

Float type: 5 gram = ref. 9450.2

Engine connection = Clamp 26/24

Air connection = M32x1.25 (thread)

Want to give your Dell'orto carburetor a different configuration than the standard?

Part broken or lost?

You can find the individual Dell'orto parts on the following pages of this category.
